All-in-One Video Wall player-MDS-DP16H-20_s All-in-One Video Wall player-MDS-DP16H-20_f All-in-One Video Wall player-MDS-DP16H-20_b
All-in-One Video Wall player-MDS-DP16H-20_s All-in-One Video Wall player-MDS-DP16H-20_f All-in-One Video Wall player-MDS-DP16H-20_b


Powered by NVIDIA highly powerful discrete GPU
Intel 9th gen. Coffee lake i7-9750H, 6 Cores/12 Threads CPU, 12M cache
Drive up to 16 displays with single GPU, hardware and software integrated into video wall AIO player
Max. 15360x2400 @60Hz (8x2) high resolution, support 1920x1200 per port
High performance 8K video decoder engine
Support LCD, LED video wall
Support hardware D3D accelerator, GoogleMap, 3D gaming and AutoCAD 3DMax
Integrate signage software, editor schedule and remoted control
Customized configuration to replace the original pre-sets, enabling faster setups


Aetina Multi Monitors Marvel M3 Player series are the hardware and software integrated all-in-one high-performance control player for the video wall. Built to leverage the power of cutting-edge discrete GPU to provide 1:1 pixel to pixel meticulous output quality and unprecedented 8K video decoding, displaying, and streaming.

M3 Player MDS-DP16H-20 supports 4K x4 or FHD x8 channel video capture input for option, driving a multi-monitor video wall configuration on 4x4 or 8x2 as a large workplace with optimal Ultra HD 8K video playback abilities. Besides, backup by Aetina’s MView Power professional signage software effectively allows for easy-to-use content management. The all-in-one, powerful system transforms video wall implementation in a simple, flexible, and superior way.


Amplify 8K/16K Video Streaming with Powerful GPU-acceleration

Aetina M3 Player series take super 6-cored of Intel i7 CPU and GPU-accelerated performance of a discrete GPU card, bringing multi-monitor matrix as a single large workspace with 1:1 pixel to pixel and high-resolution display without any pixel loss. A host of the large 8GB GDDR6 graphics frame buffer memory, the highest memory bandwidth, and the individual 3D engine, MDS-DP16H-20 empowers a visually appealing video experience with the Ultra HD 8K @60Hz video playback, no matter on 4x4 (7680x4800 @60Hz) or 8x2 (15360x2400).

Support EDID Caching

Support built-in default and hardware EDID, optimizing the displaying quality and stability.

Design Custom Configuration with Aetina MView Power™ Software
Enjoy Immersive View with Convenience

Aetina MView Power™ is the brilliant, intuitive, and easy-installation video-wall editing and management software. Support the editable player, scheduling, local control, and remote monitoring. It is built inside the M3 Player and also supports for Aetina M3 Box. With MView Power, integrators can define display format, as well as efficiently execute advanced pictures and videos. It simplifies the process of video wall content design and management, enabling setup in three quick steps - selecting objects, edit, and play. Powered by the advanced GPU-accelerated hardware performance, MView Power features dynamic multi-layer object mixing and flashing animation for desirable visual effects.

Key Features

  • Edit to go, user-friendly
  • Support multimedia file format, painting and scheduling functions
  • Easily design elaborate displays of all sizes and configurations
  • Customize configurations to replace the original pre-sets, enabling faster thematic setups
  • Providing unprecedented 8K video playing and 3D visual effects1
  • Extended view-customized area, support PowerPoint or any application in mirror view

Ease to Remote Control, Edit and Monitoring

Providing the console mode, which efficiently make content editing, preview and monitoring directly at the remote end.

Quick & Easy

1. Intuitive & User Friendly Operation UI

2. Scheduling & Report

3. Multimedia File Format Support

Note 1 : 8K video playing and 3D visual effects are subject to at least 8GB memory size of the GPU graphics card.


Catalyst your engaging information through Aetina M3 video wall products, whether in a retail store, enterprise building, control room, or public spaces.

  • Medical
  • Traffic
  • Hypermarket
  • Digital Signage
  • Intelligent Surveillance System
  • Enterprises
  • Tradeshow

Use Case


Model Number
System Specs
Intel 9th Generation Coffee lake i7-9750H
6 Cores/12 Threads CPU, 12M cache
Intel QM370
2 x SO-DIMM, 2x 8GB DDR4
1x Intel Wireless-AC 9462NGW M.2 2230 , BT5.0
2x Realtek RTL8111H-CG Gigabit Ethernet controller
Audio Codec
1x ALC892-GR 7.1+2 Channel high-definition audio CODEC
Mass Storage
1x M.2 SSD slot (PCIe x4, NVMe SATA III auto detect)
1x 2.5” SATAIII HDD/SSD bay
Graphics Specs
Memory Size
Memory Clock
14.0 Gbps
Memory Interface Width
Display Support
Max. Displays
Max. Video Wall Resoultion
7680x4800 @60Hz (4 x 4 mode)
15360x2400 @60Hz (2 x 8 mode)
Max. Displays Output per Port
HDMI1.4 1920x1200 @60Hz
I/O Interface
Video Outputs
16x HDMI + Console x 1
2x RJ45 for Gigabit LAN
2x WiFi Antenna
4x USB 3.0 Type-A
4x USB 3.1 Type-A
1x D-Sub for RS-232
2x Microjack audio connectors for Mic / Line Out
1x Power button with LED
2x LEDs for HDD/WiFi
Mechanical & Environment
Operation System
Windows® 10 Pro pre-installed
Power Supply
19.5V / 350 W Power Supply
Dimensions (mm)
321.5(L) x 209.8(L) x 114.5(H) mm excluding mounting plate and protruded portion
Operating Temperature
0 ~ + 35°C
Storage Temperature
-10°C to +85°C


Ordering Information

Model Number Description
MDS-DP16H-20 Intel Core™ i7-9750H, 2 x SO-DIMM DDR4, Discrete GPU card , 8GB GDDR6 256-bits GPU card,16 x HDMI outputs, 350W PSU , 0°C to +45°C


Model Name File Name OS Version Update Date Download
MDS-DP16H-20 Aetina_MDS_MDS-DP16H-20_datasheet v1.0 2020-12-09 View
