AIE-KX11/12/21/22
• 搭載NVIDIA® Jetson AGX Orin™ 32GB/64GB運算核心
• 最高可達275 TOPS的AI算力
• 寬輸入電壓設計：9至36VDC
• 具有一組B-Key、一組E-Key、一組M-Key插槽
• 具有一組GbE、一組10GbE、2/4組IEEE 802.3af GbE PSE連接埠
• 支援Innodisk頻外遠端管理模組
• 作業温度：-25°C至+70°C
 |
產品介紹
| •八倍AI算力實現低延遲AI推論 |
| NVIDIA Jetson AGX Orin運算核心提供最高275 TOPS算力，是NVIDIA® Jetson AGX Xavier™ 32GB運算模組的八倍以上。此系統內建2048 NVIDIA® CUDA® cores及64 Tensor Cores，能在邊緣端實現伺服器等級、低延遲的AI推論。 |
| •完善的M.2擴充及區域網路連接埠 |
| AIE-KX11/12/21/22作為具有高擴充性的系統，內建一組支援LTE/5G的M.2 B-Key、一組支援Wifi/藍牙的M.2 E-Key、一組支援儲存硬體擴充的M.2 M-Key。在網路方面，該系統搭載的2或4組的PSE連接埠能夠支援2或4組POE cameras，加上一組10GbE連接埠，提供了最高100億位元/秒的高速數據傳輸功能，比傳統GbE標準高了10倍。 |
| •寬輸入電壓及寬作業溫度設計，適用多種嵌入式應用 |
|
為了能適用於多種嵌入式應用，特別是如智慧工廠、智慧城市、智慧交通等涉及嚴苛環境的場域，AIE-KX11/12/21/22能夠在-25°C至+70°C內正常運行，並支援9至36VDC的寬輸入電壓。 |
產品規格
| Model Number | AIE-KX11-1-A2 | AIE-KX12-1-A2 | AIE-KX21-1-A2 | AIE-KX22-1-A2 |
| Module Compatibility | NVIDIA Jetson AGX Orin 32GB | NVIDIA Jetson AGX Orin 64GB | ||
| AI Performance | 200 TOPS | 275 TOPS | ||
| GPU | 1792-core NVIDIA Ampere GPU with 56 Tensor Cores | 2048-core NVIDIA Ampere GPU with 64 Tensor Cores | ||
| CPU | 8-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3 | 12-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3 | ||
| Memory | 32 GB 256-bit LPDDR5 204.8 GB/s | 64GB 256-bit LPDDR5 204.8 GB/s | ||
| Storage | 64GB eMMC 5.1 | |||
| Display | 1 x HDMI 2.0 Type A | |||
| Audio | Line-out / Line-in / Mic (optional with daughter board) | |||
| TPM | TPM v2.0 (optional) | |||
| LAN | 1 x RJ-45 1GbE port 1 x RJ-45 10GbE port |
|||
| PoE Interface | 2 x RJ-45 GbE PSE | 4 x RJ-45 GbE PSE | 2 x RJ-45 GbE PSE | 4 x RJ-45 GbE PSE |
| *IEEE 802.3af compliant, 15 W per port; PSE ports 1 & 2 support IEEE 802.3at; total PSE power up to 60 W | ||||
| USB | 2 x USB 3.2 Gen 1 Type-A 1 x USB 3.2 Gen 2 Type-C 1 x USB 2.0 (DB-15) 1 x USB 2.0 OTG Type-C |
|||
| I/O Interfaces | 5 x GPIO 2 x I²C 2 x UART 2 x CAN 2.0b (Isolated, CAN FD supported) 1 x SPI 1 x RS-232 1 x RS-422/485 (2-in-1) |
|||
| Expansion | 1 x M.2 B-Key 3042/3052 (LTE/4G/5G) 1 x M.2 E-Key 2230 (Wi-Fi/BT) 1 x M.2 M-Key 2280 (NVMe, PCIe Gen 4 x4) 1 x microSD card slot 1 x micro SIM card slot 1 x OOB (out-of-band, opt ional) |
|||
| MISC. Function | 1 x Power button, 1 x Recovery button, 1 x Reset button | |||
| Power Input / Connector | DC-in 9–36 VDC, 4-pin DC jack power connector | |||
| Power Consumption | Idle: 14.3 W Full Loading: 115.8* W |
Idle: 14.8 W Full Loading: 136.8* W |
||
| *For more test condition information, please refer to user manual | ||||
| Dimension (WxDxH) | 220 x 170 x 79 mm (8.66 x 6.69 x 3.11 in) | |||
| Mounting | Wall mount (optional) / Din rail (optional) | |||
| Net Weight | 1.852 kg (4 lb) | |||
| Vibration | 1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis | |||
| Shock | 10 G, IEC 60068-2-27, half sine, 11 ms duration | |||
| Temperature | Operat ing Temp.: -25°C – 70°C (-13°F – 158°F) with 0.5 m/s airflow Super Mode: No thermal throttling under full CPU and GPU load at 65°C Storage Temp.: -40°C – 85°C (-40°F – 185°F) |
|||
| Humidity | 95% @ 40°C (104°F) (non-condensing) | |||
| Software Support | Linux (supports NVIDIA® Jetpack 6.2 and above) | |||
| Certification | CE, FCC Class A, UKCA | |||
產品規格
Written in preliminary datasheet
Model Number
AIE-KX11/12/21/22
訂購訊息
| Model Number | Description |
|---|---|
|
AIE-KX11-1-A2 |
AGX ORIN 32GB + carrier board + FAN + chassis + power adaptor + US power cord with 2 PSE ports, -25°C to +70°C |
|
AIE-KX12-1-A2 |
AGX ORIN 32GB + carrier board + FAN + chassis + power adaptor + US power cord with 4 PSE ports, -25°C to +70°C |
|
AIE-KX21-1-A2 |
AGX ORIN 64GB + carrier board + FAN + chassis + power adaptor + US power cord with 2 PSE ports, -25°C to +70°C |
|
AIE-KX22-1-A2 |
AGX ORIN 64GB + carrier board + FAN + chassis + power adaptor + US power cord with 4 PSE ports , -25°C to +70°C |
