• 支援NVIDIA Jetson Orin™ NX and Orin Nano™ 模組
• 寬輸入電壓設計:12至24VDC
• 完整M.2: B-Key、E-Key、M-Key各一組 (內建NVMe128GB)
• 2 x RJ-45 GbE Ports
• 支援宜鼎國際(Innodisk)頻外遠端管理模組
• 作業溫度-25°C ~ +80°C
● 體積最小的Jetson模組 高達80倍的AI效能可實現AI推理 |
NVIDIA Jetson Orin™ NX模組提供高達100 TOPS的效能,是NVIDIA Jetson AGX Xavier™模組的3倍多,NVIDIA Jetson Xavier™ NX模組的5倍左右;NVIDIA Jetson Orin Nano™提供高達40 TOPS的效能,是NVIDIA Jetson Nano™模組的80倍。換言之,NVIDIA Jetson Orin NX和Orin Nano模組為體積最小的Jetson模組建立了新的主流和入門級邊緣AI標準。 |
● 豐富M.2介面 內外儲存擴充兼備 |
AIB-MO22/32和AIB-MN32/42是擴充能力高的邊緣運算平台,提供1組M.2 B-Key用於LTE/5G、1組M.2 E-Key用於Wifi/BT、1組M.2 M-Key用於儲存。為了避免邊緣運算的資料儲存空間不足,更支援外部M.2 2242 NVMe的高速傳輸與擴充。 |
● 寬輸入電壓和作業溫度 適用於各種嵌入式應用 |
為滿足各種嵌入式應用,尤其是具有挑戰性的環境,如智慧工廠、智慧城市和智慧交通等,AIB-MO22/32和AIB-MN32/42支援作業溫度範圍從-25°C到80°C,寬輸入電源範圍則為12到24VDC。 |
Model Number | AIB-MO22 | AIB-MO32 | AIB-MN32 | AIB-MN42 |
AI Performance | 20 TOPS | 40 TOPS | 70 TOPS | 100 TOPS |
Module Compatibility | NVIDIA Jetson Orin Nano 4GB | NVIDIA Jetson Orin Nano 8GB | NVIDIA Jetson Orin NX 8GB | NVIDIA Jetson Orin NX 16GB |
GPU | 512 Core NVIDIA Ampere, with 16 Tensor Cores | 1024 Core NVIDIA Ampere, with 32 Tensor Cores | 1024 Core NVIDIA Ampere, with 32 Tensor Cores | |
CPU | 6-core Arm® Cortex®-A78AE v 8.2 64-bit 1.5MB L2 + 4MB L3 | 6-core Arm® Cortex®-A78AE v 8.2 64-bit 1.5MB L2 + 4MB L3 | 8-core Arm® Cortex®-A78AE v 8.2 64-bit 2MB L2 + 4MB L3 | |
Memory | 4GB 64-bit LPDDR5 34GB/s | 8GB 128-bit LPDDR5 68GB/s | 8GB 128-bit LPDDR5 @ 2133 HMz 102.4 GB/s | 16GB 128-bit LPDDR5 @ 2133 HMz 102.4 GB/s |
Storage | 1 x M.2 M-Key 2242 (NVMe 128GB built-in) | |||
Display | 1 x HDMI 2.0 Type A | |||
Audio | Line-out / Line-in / Mic (optional with daughter board) | |||
RTC | With super capacitor, battery (optional) | |||
Camera Input | 1x 8-Lane MIPI Expansion Connector (120 Pin) | |||
LAN | 2 x RJ-45 GbE ports | |||
USB | 2 x USB 3.2 Gen2 Ty pe A (supports up to 10Gbps shared) 1 x OTG Ty pe-C |
|||
I/O Interfaces | 5 x GPIO, 1 x SPI, 1 x I2S, 3 x I2C, 1 x UART, 1 x UART (Debug Only ), 1 x RS-232, 1 x CAN (Isolation; support CAN FD), 1 x RS-422/485 (2-in1), 1 x microSIM Card Slot |
|||
Expansion | 1 x M.2 B-Key 3042/3052 (LTE/4G/5G) 1 x M.2 E-Key 2230 (WiFi/BT) 1 x M.2 M-Key 2242 (NVMe 128GB built-in) |
|||
MISC. Function | 1 x Recovery / Reset Button | |||
Power Consumption | Idle: 7 W Full Loading: 28.68* W |
Idle: 7.3 W Full Loading: 39* W |
||
*For more test condition information, please refer to user manual | ||||
Power Input/Connector | DC-in 12 to 24 VDC / 4-pin DC Jack Power Connector | |||
Dimension (WxDxH) | 120 x 100 x 57.54 mm (4.73 x 3.94 x 2.27") | |||
Net Weight | 0.195 kg (0.43 lb) | |||
Vibration |
1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
|||
Shock |
10 G, IEC 60068-2-27, half sine, 11 ms duration |
|||
Temperature |
Operating Temp. -25°C ~ +80°C (-13°F ~ +176°F) |
|||
Humidity | 95% @ 40°C (104°F) (non-condensing) | |||
Software Support | Linux (Support Jetpack 5.0 above) | |||
Certification | CE / FCC Class A / UKCA |
Model Number | Description |
---|---|
AIB-MO22-1-A1 |
Orin Nano 4GB, 1 x HDMI, 2 x GbE, 2 x USB, 128GB SSD, B/E/M Key, 12 to 24 VDC input, -25°C~+80°C |
AIB-MO32-1-A1 |
Orin Nano 8GB, 1 x HDMI, 2 x GbE, 2 x USB, 128GB SSD, B/E/M Key, 12 to 24 VDC input, -25°C~+80°C |
AIB-MN32-1-A1 |
Orin NX 8GB, 1 x HDMI, 2 x GbE, 2 x USB, 128GB SSD, B/E/M Key, 12 to 24 VDC input, -25°C~+80°C |
AIB-MN42-1-A1 |
Orin NX 16GB, 1 x HDMI, 2 x GbE, 2 x USB, 128GB SSD, B/E/M Key, 12 to 24 VDC input, -25°C~+80°C |
