AIE-PX11/12/21/22
• 支援NVIDIA Jetson AGX Orin™ 32GB/64GB模組
• 具有2/4組IEEE 802.3af GbE PSE連接埠
• 具有一組GbE、一組10GbE
• 具有一組B-Key、一組E-Key、一組M-Key插槽
• 寬輸入電壓設計：9至36VDC
• 作業溫度-25°C ~ +55°C
• 無風扇設計
 |
產品介紹
| • 八倍AI算力實現低延遲AI推論 |
| NVIDIA Jetson AGX Orin運算核心提供最高275 TOPS算力，是NVIDIA Jetson AGX Xavier™ 32GB運算模組的八倍以上。此系統內建2048 NVIDIA CUDA®cores及64 Tensor Cores，能在邊緣端實現伺服器等級、低延遲的AI推論。 |
| • 完善的M.2擴充、PSE及區域網路連接埠 |
| AIE-PX11/12/21/22作為具有高擴充性的系統，內建一組支援LTE/5G的M.2 B-Key、一組支援Wifi/藍牙的M.2 E-Key、一組支援儲存硬體擴充的M.2 M-Key。在網路方面，該系統搭載的2或4組的PSE連接埠能夠支援2或4組POE cameras，加上一組10GbE連接埠，提供了最高100億位元/秒的高速數據傳輸功能，比傳統GbE標準高了10倍。 |
| • 寬輸入電壓和無風扇設計 適用於智慧城市和智慧農業 |
|
為了滿足智慧城市和智慧農業等各種應用的需求，高成本效益的維護和高可靠性至關重要。因此，AIE-PX11/12/21/22特別設計了無風扇和靜音機制、能在-25°C至55°C的作業溫度範圍內運作。此外，支援9至36 VDC的廣輸入電源範圍，提供彈性的電源供應選擇。 |
* AIE-PX11/12/21/22 目前是初步的產品，其規格可能在無提前通知下有所變動及調整。
產品規格
| Model Number | AIE-PX11 | AIE-PX12 | AIE-PX21 | AIE-PX22 |
| Module Compatibility | NVIDIA Jetson AGX Orin 32GB | NVIDIA Jetson AGX Orin 64GB | ||
| AI Performance | 200 TOPS | 275 TOPS | ||
| GPU | 1792-core NVIDIA Ampere GPU with 56 Tensor Cores | 2048-core NVIDIA Ampere GPU with 64 Tensor Cores | ||
| CPU | 8-core Arm® Cortex® -A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3 | 12-core Arm® Cortex® -A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3 | ||
| Memory | 32GB 256-bit LPDDR5 204.8 GB/s | 64GB 256-bit LPDDR5 204.8 GB/s | ||
| Storage | 64GB eMMC 5.1 | |||
| Display | 1 x HDMI 2.0 Type A | |||
| TPM | TPM v2.0 (optional) | |||
| LAN | 1 x RJ-45 GbE, 1 x RJ-45 10GbE | |||
| PoE Interface | 2 x RJ-45 GbE PSE (IEEE 802.3af compliant, Power Output 15W/Port)* |
4 x RJ-45 GbE PSE (IEEE 802.3af compliant, Power Output 15W/Port)* |
2 x RJ-45 GbE PSE (IEEE 802.3af compliant, Power Output 15W/Port)* |
4 x RJ-45 GbE PSE (IEEE 802.3af compliant, Power Output 15W/Port)* |
| *PSE Port 1 & Port 2 support IEEE 802.3at compliant; Total PSE ports support up to 60W | ||||
| USB | 2 x USB 3.2 Gen1 Ty pe A, 1 x USB 2.0 (DB-15), 1 x OTG Ty pe-C, 1 x USB 3.2 Gen2 Ty pe-C/td> | |||
| I/O Interfaces | 2 x I2C, 1 x SPI, 5 x GPIO, 2 x UART, 1 x RS-232, 1 x RS-422/485 (2-in-1), 2 x CAN 2.0b (isolation; support CAN FD), 1 x microSIM Card Slot, 1 x OOB (optional) |
|||
| Expansion | 1 x M.2 B-Key 3042/3052 (LTE/4G/5G) 1 x M.2 E-Key 2230 (WiFi/BT) 1 x M.2 M-Key 2280 (supports NVMe; PCIe x2 Gen3) 1 x microSD Card Slot |
|||
| MISC. Function | 1 x Power / 1 x Recovery / 1 x Reset Button | |||
| Power Input/Connector | DC-in 9 to 36 VDC / 4-Pin DC Jack Power Connector | |||
| Power Consumption | Idle: 7.5 W Full Loading: 109* W |
Idle: 8 W Full Loading: 130* W |
||
| *For more test condition inf ormation, please ref er to user manual | ||||
| Dimension (WxDxH) | 270 x 195 x 80 mm (10.63 x 7.67 x 3.15 in) | |||
| Mounting | Wall Mount (optional) / Din Rail (optional) | |||
| Net Weight | 4.3 kg (9.48 lb) | |||
| Vibration | 1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis | |||
| Shock | 10 G, IEC 60068-2-27, half sine, 11 ms duration | |||
| Temperature | Operating Temperature: -25°C ~ +55°C (-13°F ~ +131°F) with 0.5 m/s air flow Storage Temperature: -40°C ~ +85°C (-40°F ~ +185°F)Storage Temperature: -40°C ~ +85°C (-40°F ~ +185°F) |
|||
| Humidity | 95% @ 40°C (104°F) (non-condensing) | |||
| Software Support | Linux (Support Jetpack 5.0 above) | |||
| Certification | CE / FCC Class A / UKCA | |||
*Product specifications are subject to change without prior notice
產品規格
訂購訊息
| Model Number | Description |
|---|---|
|
AIE-PX11-1-A1 |
AGX Orin 32GB, 1 x HDMI, 1 x GbE, 1 x 10GbE, 2 x PoE, 3 x USB, B/E/M Key, 9 to 36 VDC input, -25°C ~ +55°C |
|
AIE-PX12-1-A1 |
AGX Orin 32GB, 1 x HDMI, 1 x GbE, 1 x 10GbE, 4 x PoE, 3 x USB, B/E/M Key, 9 to 36 VDC input, -25°C ~+55°C |
|
AIE-PX21-1-A1 |
AGX Orin 64GB, 1 x HDMI, 1 x GbE, 1 x 10GbE, 2 x PoE, 3 x USB, B/E/M Key, 9 to 36 VDC input, -25°C ~ +55°C |
|
AIE-PX22-1-A1 |
AGX Orin 64GB, 1 x HDMI, 1 x GbE, 1 x 10GbE, 4 x PoE, 3 x USB, B/E/M Key, 9 to 36 VDC input, -25°C ~ +55°C |
