AIE-VN34/44-128-A1 | AIE-VO24/34-128-S1
• Supports NVIDIA® Jetson Orin™ NX / Orin Nano™ with Super Mode
• Supports up to 4 x GMSL2 cameras
• Wide Power Input Range 9 to 36 VDC
• 1 x RJ-45 GbE Port
• Support M.2 E/M Key expansion
• Operating Temp: -25°C ~ +55°C
• E-Mark compliance (E-24 certified)
 |
Overview
Palm-Sized Intelligence in Motion
Compact In-Vehicle Edge AI System with Four Long-Range GMSL2 Cameras and Integrated Ignition-Based Safety Control
As AI-powered vision systems become increasingly essential across smart cities, intelligent transportation, and industrial automation, how can high-quality multi-camera video streams be processed in real time within space-constrained environments?
Aetina introduces the AIE-VN34/44 | AIE-VO24/34, palm-sized In-Vehicle Edge AI Systems powered by NVIDIA Jetson Orin NX / Orin Nano modules, delivering up to 100 TOPS of AI performance. Featuring support for up to four GMSL2 (Fakra-Z) cameras, the system enables real-time AI inference and 360-degree environmental perception while maintaining a compact footprint for deployment in confined spaces.
Ideal for smart transportation, surround-view vehicle monitoring, indoor Autonomous Mobile Robots (AMRs), smart factories, and automated production lines, it combines compact design, rugged durability, ignition-based safety control, and wide-temperature operation to bring reliable AI vision wherever intelligent mobility and automation are required.
Available configurations:
- AIE-VN34/44-128-A1, powered by NVIDIA Jetson Orin NX 8GB / 16GB, delivers up to 100 TOPS
- AIE-VO24/34-128-S1, powered by NVIDIA Jetson Orin Nano with Super Mode 4GB / 8GB, delivers up to 67 TOPS
Product Benefits
| Product Benefits | Description |
|---|---|
| Edge AI Powered by NVIDIA Jetson Orin |
▪ Powered by NVIDIA Jetson Orin NX / Orin Nano modules, delivering up to 100 TOPS of AI performance for advanced edge AI applications. ▪ Optimized BSP (Board Support Package) and long-term technical support from Aetina, an NVIDIA Elite Partner, ensuring ultra-low latency AI inference and maximum power efficiency when processing multiple networks and real-time video analytics. |
| Palm-Sized Design with Rugged Reliability |
▪ Ultra-compact 136.3 x 132 x 63 mm form factor, ideal for space-constrained deployments in vehicles, AMRs, industrial equipment, and edge AI systems. ▪ Having passed MIL-STD-810H shock and vibration testing, the series provides dependable operation in demanding mobile and industrial environments. |
| Multi-Camera AI Vision with GMSL2 |
▪ Supports up to 4 × GMSL2 (Fakra-Z) camera interfaces for long-distance, low-latency, and interference-resistant image transmission. ▪ Enables real-time multi-camera AI inference and 360° environmental perception for intelligent monitoring and situational awareness. |
| Intelligent Power Management |
▪ Wide 9–36V DC input for stable operation across vehicle and industrial power systems. ▪ Integrated Ignition Power Control protects against power fluctuations and supports safe startup and shutdown procedures. |
Application Scenario
| Targeted Applications | Description | Product Benefits |
|---|---|---|
| Smart Transportation | Surround-view monitoring, blind-spot detection, and AI video analytics for commercial vehicles. | ▪ 4× GMSL2 cameras for 360° vision. ▪ Ignition Power Control for vehicle integration. |
| Indoor AMR & Logistics Automation | Warehouse robots and AGVs for obstacle avoidance, path planning, and automated cargo identification. | ▪ Multi-camera sensing. ▪ Palm-sized form factor to reduce payload burden. ▪ Rugged design supports continuous operation in industrial environments. |
| Smart Factories & Production Lines | Real-time defect detection, parts counting, and personnel safety monitoring on automated lines.
|
▪ Up to 100 TOPS AI performance for real-time, high-resolution vision analytics. ▪ Low-power design simplifies thermal management. |
| Smart Retail & Buildings | In-building people tracking, shelf analysis, or automated security inspection robots. |
▪ Compact design for rapid integration in space-constrained environments. ▪ GMSL2 connectivity ensures signal integrity. |
Specifications
| Model Number | AIE-VO24-128-S1 |
AIE-VO34-128-S1 |
AIE-VN34-128-A1 |
AIE-VN44-128-A1 |
| AI Performance | 34 TOPS | 67 TOPS | 70 TOPS | 100 TOPS |
| Module Compatibility | NVIDIA Jetson Orin Nano with Super Mode 4GB | NVIDIA Jetson Orin Nano with Super Mode 8GB | NVIDIA Jetson Orin NX 8GB | NVIDIA Jetson Orin NX 16GB |
| GMSL | 4 x GMSL2 via Fakra Z | |||
| GPU | 512 Core NVIDIA Ampere, with 16 Tensor Cores |
1024 Core NVIDIA Ampere, with 32 Tensor Cores |
1024 Core NVIDIA Ampere, with 32 Tensor Cores |
1024 Core NVIDIA Ampere, with 32 Tensor Cores |
| CPU | 6-core Arm® Cortex®-A78AE v8.2 64-bit CPU 1.5MB L2 + 4MB L3 |
6-core Arm® Cortex®-A78AE v8.2 64-bit CPU 1.5MB L2 + 4MB L3 |
6-core Arm® Cortex®-A78AE v8.2 |
8-core Arm® Cortex®-A78AE v8.2 |
| Memory | 4GB 64-bit LPDDR5 34 GB/s |
8GB 128-bit LPDDR5 68 GB/s |
8GB 128-bit LPDDR5 102.4 GB/s |
16GB 128-bit LPDDR5 102.4 GB/s |
| Storage | 1 x M.2 M-Key 2242 (128GB built-in) | |||
| Display | 1 x HDMI 2.0b Type-A | |||
| RTC | With super capacitor (RTC battery CR2032, optional) | |||
| LAN | 1 x RJ-45, 1GbE | |||
| USB | 2 x USB 3.2 Gen 2, Type-A (supports up to 10Gbps shared) 1 x OTG, USB 2.0, Type-C |
|||
| I/O Interfaces |
1 x DB9, GPIO (2 x Digital Input, 3 x Digital Output, default) / RS-232 *by request |
|||
| Expansion |
1 x M.2 M-Key 2242 slot (supports NVMe, PCIe Gen3 x4, 128GB build-in) |
1 x M.2 M-Key 2242 slot (supports NVMe, PCIe Gen4 x4, 128GB build-in) 1 x M.2 E-Key 2230 slot (supports Wi-Fi/Bluetooth, PCIe Gen4 x1) 1 x microSD card socket (occupy M.2 E-Key slot, optional) |
||
| MISC. Function | 1 x Recovery button, 1 x Reset button | |||
| Power Input / Connector | DC-in 9 -36V DC, 3-Pin (V+/V-/IGN) Terminal Block *Voltage below 9V may cause the device to shut down or function abnormally. |
|||
| LED Indicator | 1 x PWR (w/ IGN), 1 x PGM (user-configurable) | |||
| Power Consumption | Idle: 9.34 W FullLoading: 51.6 W |
Idle: 9.7 W Full Loading: 51.6 W |
||
| *For more test condition information, please refer to user manual | ||||
| Dimension (WxDxH) | 136.3 x 132 x 63 mm (5.37 × 5.20 × 2.48 in) | |||
| Mounting | Wall Mount / Din Rail (optional) | |||
| Net Weight | 1.36 kg (2.99 lb) / 2.07 kg (4.56 lb) | |||
| Vibration |
Operating, MIL-STD-810H, Method 514.8, Category 4 |
|||
| Shock |
Operating, MIL-STD-810H, Method 516.8, Procedure I, 20G / 11 ms |
|||
| Temperature |
Operating Temp.: -25°C ~ +55°C (-13°F ~ +131°F) with 0.5 m/s air flow |
|||
| Humidity | 95% @ 40°C (104°F) (non-condensing) | |||
| Software Support | Linux (supports NVIDIA JetPack™ 6.2 and above) | |||
| Certification | CE, FCC Class A, E-Mark (E24), UKCA | |||
*by request: By default, the DB9 port is configured as GPIO. RS-232 is available by request and must be specified before placing an order. The requested interface will be configured during product assembly before shipment.
Why Aetina
| Value-Added Points | Description |
|---|---|
| NVIDIA Elite Partner | Priority access to NVIDIA technologies and NVIDIA Jetson products, helping clients innovate faster and scale within the NVIDIA ecosystem. |
| End-to-End Customization and Integration | From chassis and thermal design to BSP integration, Aetina partners with customers throughout solution planning and system validation, providing tailored solutions with detailed test reports to meet every unique deployment requirement. |
| Collaborative AI Deployments | With over a decade of edge AI expertise and a robust ecosystem, Aetina provides comprehensive technical and team support to simplify integration and accelerate time to deployment.
|
| Rich Set of Validated Peripherals |
Backed by NVIDIA ecosystem partners and the Innodisk Group, Aetina offers a wide range of fully validated peripherals—including storage, cameras, Wi-Fi, and 4G/5G—reducing integration time and overall system cost. |
FAQ
| Question | Answer |
|---|---|
| What professional compliance certifications do AIE-VN34/44 | AIE-VO24/34 possess? | The series has been tested to MIL-STD-810H for vibration and shock resistance and is also E-Mark certified. This demonstrates compliance with applicable UNECE regulations for automotive electronic equipment, enabling faster integration and deployment in global automotive markets. |
| How does this In-Vehicle Computing System maintain thermal performance in space-constrained environments? | Aetina utilizes a specialized structural thermal design. The fanless architecture not only minimizes maintenance costs but also ensures stable, throttless operation even under extreme industrial wide-temperature ranges (-25°C to +55°C (-13°F ~ +131°F)). |
| Where can I purchase these products? | To request a quote or place an order, please contact Aetina Sales or click here directly. |
Specifications
Dimensions
Ordering Information
| Model Number | Description |
|---|---|
|
AIE-VN44-128-A1 |
ORIN NX 16GB, 1 x HDMI, 1 x GbE, 2 x USB-A, E/M Key, 9 to 36 VDC input, 3TE4 128GB, FAKRA x4, -25°C ~ +55°C |
|
AIE-VN34-128-A1 |
ORIN NX 8GB, 1 x HDMI, 1 x GbE, 2 x USB-A, E/M Key, 9 to 36 VDC input, 3TE4 128GB, FAKRA x4, -25°C ~ +55°C |
|
AIE-VO34-128-S1 |
ORIN Nano 8GB-S, 1 x HDMI, 1 x GbE, 2 x USB-A, E/M Key, 9 to 36 VDC input, 3TE4 128GB, FAKRA, x4, -25°C ~ +55°C |
|
AIE-VO24-128-S1 |
ORIN Nano 4GB-S, 1 x HDMI, 1 x GbE, 2 x USB-A, E/M Key, 9 to 36 VDC input, 3TE4 128GB, FAKRA x4, -25°C ~ +55°C |
