AIE-PO23/33-3M | AIE-PN33/43-3M
• Support NVIDIA Jetson Orin™ NX and Orin Nano™ module
• 2 x RJ-45 GbE ports
• 1 x M.2 B-Key, 1 x M.2 E-Key slot
• 3 x M.2 M-Key slot for NVMe storage, CAN, RS-232/RS-422/485 expansion
• Wide input voltage range from 12 to 24 VDC
• Operating Temperature -25°C ~ +55°C
• Fanless Design
• Supports device remote management via EdgeEye
 |
Overview
Spotting as a reliable and powerful AI inference device, the Aetina fanless and versatile expansion edge AI system - AIE-PN33/43-3M is designed to incorporate a vast M.2 expandability. Coupled with versatile I/O and Ethernet ports, it meets various needs of AI deployment. Powered by an NVIDIA® Jetson Orin™ NX, the AIE-PN33/43-3M delivers up to 100 TOPS of AI performance and is also compatible with the NVIDIA® Jetson Orin Nano™ module, as demonstrated by our release of the AIE-PO23/33-3M. Both systems offer users full bandwidth and power packages to accelerate and scale data connectivity for AI inference at the edge.
| ● Up to 100 TOPS AI performance enables AI inference on the Edge |
| AIE-PN33/43-3M and AIE-PO23/33-3M are fully compatible with NVIDIA Jetson Orin NX and Orin Nano modules, delivering exceptional AI performance and energy efficiency. Thanks to the 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores embedded in an NVIDIA Jetson Orin NX, AIE-PN33/43-3M drives up to 100 TOPS AI performance for high-resolution data processing and real-time inferencing. |
| ● Comprehensive M.2 for internal and external expansion |
| AIE-PN33/43-3M and AIE-PO23/33-3M are fanless systems with high expansion ability to support flexible and comprehensive M.2 expansion capability. Built-in 1x M.2 B-Key for LTE/5G, 1x M.2 E-Key for Wifi/BT, 3x M.2 M-Key for NVMe expansion storage for fast data transmission or extension module of CANBus, RS-232/RS-422/RS-485. By integrating with Aetina’s BSP and NVIDIA Jetpack toolkit supporting, both AIE-PN33/43-3M and AIE-PO23/33-3M are ideal for real-time AI-driven detection and recognition at roadside, wayside, farms, factory or construction sites. |
| ● Support EdgeEye for Device Remote Management |
|
AIE-PN33/43-3M and AIE-PO23/33-3M ease remote management burdens through integrated support for EdgeEye. IT staff can use Aetina’s EdgeEye cloud management platform to monitor, control, and reboot distributed edge systems conveniently from a central management console. |
* AIE-PN33/43-3M and AIE-PO23/33-3M are preliminary products, so the specifications are subject to change without prior notice.
Specifications
| Model Number | AIE-PO23-3M | AIE-PO33-3M | AIE-PN33-3M | AIE-PN43-3M |
| Module Compatibility | NVIDIA Jetson Orin Nano 4GB | NVIDIA Jetson Orin Nano 8GB | NVIDIA Jetson Orin NX 8GB | NVIDIA Jetson Orin NX 16GB |
| AI Performance | 20 TOPS | 40 TOPS | 70 TOPS | 100 TOPS |
| GPU | 512 Core NVIDIA Ampere, with 16 Tensor Cores | 1024 Core NVIDIA Ampere, with 32 Tensor Cores | 1024 Core NVIDIA Ampere, with 32 Tensor Cores | |
| CPU | 6-core Arm® Cortex®-A78AE v 8.2 64-bit 1.5MB L2 + 4MB L3 | 6-core Arm® Cortex®-A78AE v 8.2 64-bit 1.5MB L2 + 4MB L3 | 8-core Arm® Cortex®-A78AE v 8.2 64-bit 2MB L2 + 4MB L3 | |
| Memory | 4GB 64-bit LPDDR5 34GB/s | 8GB 128-bit LPDDR5 68GB/s | 8GB 128-bit LPDDR5 102.4 GB/s | 16GB 128-bit LPDDR5 102.4 GB/s |
| Storage | 1 x M.2 NVMe M-Key 2242 (128GB built-in) | |||
| Display | 1 x HDMI 2.0 Type A | |||
| TPM | Not supported | |||
| LAN | 2 x RJ-45 GbE ports | |||
| USB | 2 x USB 3.2 Gen2 Type A (support up to 10 Gbps shared) 1 x OTG Type-C |
|||
| I/O Interfaces | 5 x GPIO, 1 x UART, 1 x I2C, 1 x RS-232, 1 x RS-422/485, 1 x CAN (isolation; support CAN FD) |
|||
| Expansion | 1 x M.2 B-Key 3042/3052 (LTE/5G) 1 x M.2 E-Key 2230 (WiFi/BT) 1 x M.2 M-Key 2242 (NVMe 128GB built-in) 2 x M.2 M-Key 2280 (PCIe) |
|||
| MISC. Function | 1 x Power Button / 1 x Recovery Button / 1 x Reset Button | |||
| Power Input/Connector | DC-in 12-24VDC / 4-Pin DC Jack Power Connector | |||
| Power Consumption | Idle: 6.413 W Full Loading: 43.13* W |
Idle: 6.413 W Full Loading: 43.13* W |
||
| *For more test condition information, please refer to user manual | ||||
| Dimension (WxDxH) | 270 x 195 x 80 mm (10.63 x 7.67 x 3.15 in) | |||
| Mounting | Wall Mount (optional) / Din Rail (optional) | |||
| Net Weight | TBC kg (TBC lb) | |||
| Vibration | 1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis | |||
| Shock | 10 G, IEC 60068-2-27, half sine, 11 ms duration | |||
| Temperature |
Operating Temp. -25°C ~ +55°C (-13°F ~ +131°F) with 0.5 m/s air flow |
|||
| Humidity | 95% @ 40°C (104°F) (non-condensing) | |||
| Software Support | Linux (Support Jetpack 5.0 above) | |||
| Certification | CE / FCC Class A / UKCA | |||
*Product specifications are subject to change without prior notice
Specifications
Dimensions
Ordering Information
| Model Number | Description |
|---|---|
|
AIE-PO23-3M-1-A1 |
Orin Nano 4GB, 1 x HDMI, 2 x GbE, 2 x USB, 128GB SSD, B/E/M(x3) Key, 12 to 24 VDC input, -25°C ~ +55°C |
|
AIE-PO33-3M-1-A1 |
Orin Nano 8GB, 1 x HDMI, 2 x GbE, 2 x USB, 128GB SSD, B/E/M(x3) Key, 12 to 24 VDC input, -25°C ~ +55°C |
|
AIE-PN33-3M-1-A1 |
Orin NX 8GB, 1 x HDMI, 2 x GbE, 2 x USB, 128GB SSD, B/E/M(x3) Key, 12 to 24 VDC input, -25°C ~ +55°C |
|
AIE-PN43-3M-1-A1 |
Orin NX 16GB, 1 x HDMI, 2 x GbE, 2 x USB, 128GB SSD, B/E/M(x3) Key, 12 to 24 VDC input, -25°C ~ +55°C |
